Dorst TPA 40 powder compacting press for sintered metal ceramics carbon & carbide
FOR SALE.
Back
Home
Contact
DORST TPA40 POWDER PRESS
Can be Purchased as it stands now with manual clutch and internal oil pump
Or can be fully refurbished, with new clutch new electrics and all new shafts and bushes.
See below for Spec sheet
SPECIFICATIONS
MAX PRESSING POWER 40TONS
MAX EJECTION POWER 8TONS
UPPER RAM STROKE 175mm
MAX FILLING HEIGHT 138mm
MAX PRESSING TRAVEL 68mm
MAX EJECTION TRAVEL 70mm
MAX PRE-PRESS TRAVEL 12.5mm
STROKES PER MINUTE 5.5 TO 25
MAIN MOTOR 3.0kW-4.1HP
NETT WEIGHT 3,050Kg
OVERALL HEIGHT 2,450mm
OVERALL WIDTH 1,270mm
OVERALL DEPTH 1,250mm
